AC blows hot on drivers side cold on passenger side
#27
Super Member
WISEPC for 2015. If you go back to my filter and dealer thread you can down load it. I can walk you through if you have issues.
#28
Super Member
#29
Junior Member
Thread Starter
Join Date: Apr 2015
Location: denver colorado
Posts: 70
Likes: 0
Received 0 Likes
on
0 Posts
2001 s500 with amg factory sport package (black)
Yea ill swap those today and report back later. Thanks!! Havent tried this yet. Would the nr. Numbers on the climate control head help? The "hidden diagnostics " nubers. I can warm up the car to operating temp and write those down if it will help. Thanks again, ill report back after i swap 18 and 19
#30
Super Member
Originally Posted by Jack_88
Much appreciated.
This may take a while.
This may take a while.
#1 to #9 are what you need for the database. The rest are just trash.
#31
Super Member
Originally Posted by ssfisher
Yea ill swap those today and report back later. Thanks!! Havent tried this yet. Would the nr. Numbers on the climate control head help? The "hidden diagnostics " nubers. I can warm up the car to operating temp and write those down if it will help. Thanks again, ill report back after i swap 18 and 19
#32
Junior Member
Thread Starter
Join Date: Apr 2015
Location: denver colorado
Posts: 70
Likes: 0
Received 0 Likes
on
0 Posts
2001 s500 with amg factory sport package (black)
Roger that. Ill get 1 and 9. Im learning everyday with this car. I enjoy it tho. Those sensors look like they are behind the radio and climate controls. Is that right?
#33
Super Member
Yes. They are. I think you need to start at the ashtray then go up to the radio.
After I got my 1st S, I always wonder if I should go with the newer E. Well, I got my answer this week. I still like my older S more than this newer E.
After I got my 1st S, I always wonder if I should go with the newer E. Well, I got my answer this week. I still like my older S more than this newer E.
#34
Junior Member
Thread Starter
Join Date: Apr 2015
Location: denver colorado
Posts: 70
Likes: 0
Received 0 Likes
on
0 Posts
2001 s500 with amg factory sport package (black)
Nice. Ive got the radio and climate controls and ashtray out. I think i see the sensors behind some gray insulation. Trying to remove plugs now
#35
Junior Member
Thread Starter
Join Date: Apr 2015
Location: denver colorado
Posts: 70
Likes: 0
Received 0 Likes
on
0 Posts
2001 s500 with amg factory sport package (black)
Ok, swapped wires from left to right. They are two wire plugs. Small. I think those are sensors? Nothing changed. Still heat on drivers side cold on passenger and same 1417 code. Also reset code, no change. Here are some numbers while at idle:
Nr.00 +20,9 Nr.06 +75
01 +22,5 07 12,2 bar
02 +37 08 +40,7
03 +11 09 +9.8k
04 +45 10 5,8v
05 +4,4
Nr.00 +20,9 Nr.06 +75
01 +22,5 07 12,2 bar
02 +37 08 +40,7
03 +11 09 +9.8k
04 +45 10 5,8v
05 +4,4
#36
Super Member
That's disappointing.
What about the temp readings below?
Rest button with AC on:
0 AAC in-car temperature sensor (operating module)
1 Overhead control panel for in-car temperature sensor
2 Outside temperature sensor
3 Left heater-exchanger in car temperature sensor
4 Right heater-exchanger in-car temperature sensor
5 Evaporator core sensor
6 Engine temperature
N Refrigerant pressure
8 R134A refrigerant in-car temperature sensor
10 Blower control voltage
15 Average insolation value between 0 and 125%
16 Carbon monoxide value between 0 and 1023
17 Nitrogen oxide value between 0 and 1023
18 Dew point temperature
20 Fan output value between 0 and 100%
21 Engine speed
22 Ground speed
24 Battery voltage
27 Left hand potentiometer engine speed value between 0 and 100%
28 Centre potentiometer engine speed value between 0 and 100%
29 Right hand potentiometer engine speed value between 0 and 100%
30 Temp of blow air in left rear passenger-compartment
31 Temp of blow air in left rear passenger-compartment
32 Temp of evaporator core in rear passenger compartment
33 Blower voltage in rear passenger-compartment
34 Specified temperature in left rear passenger-compartment
35 Specified temperature in right rear passenger-compartment
40 Left hand defroster door value (open/closed plain text at limit stop)
41 Right hand defroster door value (open/closed plain text at limit stop)
42 Left hand footwell flap value between 0 and 100%
43 Right hand footwell flap value between 0 and 100%
44 Left hand blend flap value between 0 and 100%
45 Right hand blend flap value between 0 and 100%
46 Left hand diverter flap 0 and 100%
47 Right hand diverter flap value 0 and 100%
48 Recirculation door 0 and 100%
49 AKF bypass flap 0 and 100%
50 AAC Software
51 AAC Hardware
52 Software for rear passenger compartment air conditioning
53 Hardware for rear passenger compartment air conditioning
54 Software for stepper motor unit
55. Hardware for stepper motor unit
56 Software for centre nozzle
57 Hardware for center nozzle
58 Software for multifunction sensor
59 Hardware for multifunction sensor
60 Sofware for day-brightness sensor
61 Hardware for day-brightness sensor
What about the temp readings below?
Rest button with AC on:
0 AAC in-car temperature sensor (operating module)
1 Overhead control panel for in-car temperature sensor
2 Outside temperature sensor
3 Left heater-exchanger in car temperature sensor
4 Right heater-exchanger in-car temperature sensor
5 Evaporator core sensor
6 Engine temperature
N Refrigerant pressure
8 R134A refrigerant in-car temperature sensor
10 Blower control voltage
15 Average insolation value between 0 and 125%
16 Carbon monoxide value between 0 and 1023
17 Nitrogen oxide value between 0 and 1023
18 Dew point temperature
20 Fan output value between 0 and 100%
21 Engine speed
22 Ground speed
24 Battery voltage
27 Left hand potentiometer engine speed value between 0 and 100%
28 Centre potentiometer engine speed value between 0 and 100%
29 Right hand potentiometer engine speed value between 0 and 100%
30 Temp of blow air in left rear passenger-compartment
31 Temp of blow air in left rear passenger-compartment
32 Temp of evaporator core in rear passenger compartment
33 Blower voltage in rear passenger-compartment
34 Specified temperature in left rear passenger-compartment
35 Specified temperature in right rear passenger-compartment
40 Left hand defroster door value (open/closed plain text at limit stop)
41 Right hand defroster door value (open/closed plain text at limit stop)
42 Left hand footwell flap value between 0 and 100%
43 Right hand footwell flap value between 0 and 100%
44 Left hand blend flap value between 0 and 100%
45 Right hand blend flap value between 0 and 100%
46 Left hand diverter flap 0 and 100%
47 Right hand diverter flap value 0 and 100%
48 Recirculation door 0 and 100%
49 AKF bypass flap 0 and 100%
50 AAC Software
51 AAC Hardware
52 Software for rear passenger compartment air conditioning
53 Hardware for rear passenger compartment air conditioning
54 Software for stepper motor unit
55. Hardware for stepper motor unit
56 Software for centre nozzle
57 Hardware for center nozzle
58 Software for multifunction sensor
59 Hardware for multifunction sensor
60 Sofware for day-brightness sensor
61 Hardware for day-brightness sensor
#37
Super Member
My 04 S430
Nr.00 +22 Nr.06 +80
01 +22,5 07 12,2 bar
02 +35 08 +41
03 +7 09 +8k
04 +4 10 3,0v
05 +4
Is 04 a typo 4.5 and not 45?
Nr.00 +22 Nr.06 +80
01 +22,5 07 12,2 bar
02 +35 08 +41
03 +7 09 +8k
04 +4 10 3,0v
05 +4
Is 04 a typo 4.5 and not 45?
#40
Super Member
Originally Posted by ssfisher
I just started car and at idle: nr.04 +51c
Perhaps we haven't swapped the sensors yet as they placed after the plugs #18 and #19?
#41
Junior Member
Thread Starter
Join Date: Apr 2015
Location: denver colorado
Posts: 70
Likes: 0
Received 0 Likes
on
0 Posts
2001 s500 with amg factory sport package (black)
Plugs in original positions:
Nr.00 + 22,6c
Nr.01 +24,7c
Nr.02 +44c
Nr.03 +49c
Nr.04 +15c
Nr.05 +5,3c
Nr.06 +81c
Nr.07 13,3 bar
Nr.08 +44,2c
Nr.09 +9,3k
Nr.10 5,8v
Nr.00 + 22,6c
Nr.01 +24,7c
Nr.02 +44c
Nr.03 +49c
Nr.04 +15c
Nr.05 +5,3c
Nr.06 +81c
Nr.07 13,3 bar
Nr.08 +44,2c
Nr.09 +9,3k
Nr.10 5,8v
#42
Super Member
Originally Posted by ssfisher
Plugs in original positions:
Nr.00 + 22,6c
Nr.01 +24,7c
Nr.02 +44c
Nr.03 +49c
Nr.04 +15c
Nr.05 +5,3c
Nr.06 +81c
Nr.07 13,3 bar
Nr.08 +44,2c
Nr.09 +9,3k
Nr.10 5,8v
Nr.00 + 22,6c
Nr.01 +24,7c
Nr.02 +44c
Nr.03 +49c
Nr.04 +15c
Nr.05 +5,3c
Nr.06 +81c
Nr.07 13,3 bar
Nr.08 +44,2c
Nr.09 +9,3k
Nr.10 5,8v
#43
Junior Member
Thread Starter
Join Date: Apr 2015
Location: denver colorado
Posts: 70
Likes: 0
Received 0 Likes
on
0 Posts
2001 s500 with amg factory sport package (black)
So here it is:
Plugs swapped;
Nr.03 +14c
Nr.04 +51c
Plugs in original position;
Nr.03 +49c
Nr.04 +15c
With this info i would say sensors are working like they should. They are reading acual air temp
Plugs swapped;
Nr.03 +14c
Nr.04 +51c
Plugs in original position;
Nr.03 +49c
Nr.04 +15c
With this info i would say sensors are working like they should. They are reading acual air temp
#44
Junior Member
Thread Starter
Join Date: Apr 2015
Location: denver colorado
Posts: 70
Likes: 0
Received 0 Likes
on
0 Posts
2001 s500 with amg factory sport package (black)
Do you know what should happen if i unplug the dualvalve solinoids? The two small solenoids. I think the larger one is the resurculating pump? Will doing that tell us anything? And thanks for you time. Im sure you have better things to do on sunday.
#45
Super Member
Sorry I went off the grid. I haven't run into the duo but here is its function
#46
Super Member
I still think this is the sensor issue. Here is the function and the location.
On a separate note, I found the sensor location for my rear unit. Haha!
On a separate note, I found the sensor location for my rear unit. Haha!
#47
Super Member
Join Date: Sep 2012
Location: Montreal, Quebec
Posts: 676
Likes: 0
Received 69 Likes
on
63 Posts
2009 E350 4M Avantgarde;mistress 2002 S600; wife 2014 C300 4M
My $ 0.02 worth:
as mentioned before: check the voltage at the duo-valve solenoids, must be the same for both under same selections on control panel.
IF we are talking about cars with the REAR ac, note that the (separate) duo-valve for that one is in the right forward fender (incorrectly described in the WIS).
as mentioned before: check the voltage at the duo-valve solenoids, must be the same for both under same selections on control panel.
IF we are talking about cars with the REAR ac, note that the (separate) duo-valve for that one is in the right forward fender (incorrectly described in the WIS).
#48
Super Member
Originally Posted by kraut56
My $ 0.02 worth:
as mentioned before: check the voltage at the duo-valve solenoids, must be the same for both under same selections on control panel.
as mentioned before: check the voltage at the duo-valve solenoids, must be the same for both under same selections on control panel.
#49
Super Member
Join Date: Sep 2012
Location: Montreal, Quebec
Posts: 676
Likes: 0
Received 69 Likes
on
63 Posts
2009 E350 4M Avantgarde;mistress 2002 S600; wife 2014 C300 4M
yes, but in this whole saga he has NOT confirmed that both solenoids actually work.
A used unit could be just as bad, as these duo-valve are notorious to stick.
Proper trouble shooting is advised here, before going into sensors.
The solenoids can be removed to check for corrosion at the springs, and the solenoid plugs can be disconnected/connected to test for function, after verifying voltage at the plugs.
A used unit could be just as bad, as these duo-valve are notorious to stick.
Proper trouble shooting is advised here, before going into sensors.
The solenoids can be removed to check for corrosion at the springs, and the solenoid plugs can be disconnected/connected to test for function, after verifying voltage at the plugs.
#50
Super Member
Originally Posted by kraut56
yes, but in this whole saga he has NOT confirmed that both solenoids actually work.
A used unit could be just as bad, as these duo-valve are notorious to stick.
Proper trouble shooting is advised here, before going into sensors.
The solenoids can be removed to check for corrosion at the springs, and the solenoid plugs can be disconnected/connected to test for function, after verifying voltage at the plugs.
A used unit could be just as bad, as these duo-valve are notorious to stick.
Proper trouble shooting is advised here, before going into sensors.
The solenoids can be removed to check for corrosion at the springs, and the solenoid plugs can be disconnected/connected to test for function, after verifying voltage at the plugs.
