Talk about out of my league, this is out of my solar system. It's hard to zoom in on these pics., but are all those throttle butterflys being operated by what looks to be 2 electric actuators, (stepper motors?), on the back of the engine?
MBWorld Fanatic!
Joined: Nov 2004
Posts: 6,697
Likes: 381
2005 E55
.
I had these saved on my phone.
Last edited by skratch77; Apr 20, 2020 at 08:48 PM.
Member
Joined: Feb 2020
Posts: 165
Likes: 53
2014 C63 507 Coupe
Thanks for the picture Skratch77. That machine work is incredible! So that's what they've done. You can see a bore that holds a butterfly shaft that runs all the way through the bank of throttle bodies from the step motor housing. So now, (according to wikipedia), all you need to do is turn your gas pedal into an indexer, (microprocessor), that generates step pulses and direction to send signals to a driver / amplifier to convert the digital pulses into mechanical rotation. Forgetting for the moment about programming for individual injector control based on the feed back from individual O2 sensors. So simple. We should all do it. Absolutely dumbfounding custom work! (And expense no doubt!)
